Portable LED Project Lights
Great light for emergencies and for contractors working in confined spaces. No heat!
High power adjustable Cree LED portable project lights
are ideal for ham radio operators and emergency personnel. Contractors and painters - very low heat generated. Solar and battery ready model available. Click to enlarge alternate views.
Two models to choose from: 12VDC/VAC or 80-260VAC. Made in the USA
PPL 2412 VDC VAC LED Project Lights
- Input voltage: 11.4-15VDC or 10.5-14 VAC
- Draw: 18W
- Comparable Light Output: 375W
- Lumen Output: 3880 Lm
- 10 foot cord with bare wires. Power point or transformer needed
PPL 40AC Portable LED Project Lights
- Input voltage: 85-260 VAC
- Draw: 30W
- Comparable Light Output: 500W
- Lumen Output: 5640 Lm
- 6 foot cord with 120VAC plug for easy portable use
- 24 or 40 Cree XPG Series S2 5400K 180 lm per LED
- 160 degree evenly distributed light spread
- On board PWM duty 15% extends LED life over 70,000 hours
- Perforated waffle pack LED metal clad PCB design
- Honeycomb aluminum thermal coolant and protection
- Body: cast aluminum alloy, security red
- Short circuit protection
- LED project Lights are adjustable to 90 degrees
- Comes with a protective grill for sports or work
- UV filtered glass prevents damage to inner components.
- Sealed with 30 year silicone tube type gasket.
- Comes with a handle and base for easy portability
- High and low power switches
- Tubes on base can be filled with sand or mortar
- 0.25" tempered frosted glass lens
- IP Rating: IP65, indoor or outdoor use
- Mounting hardware included
- Dimensions: 10" L x 9.25" W x 5.5" D
- RoHS compliant - no Pb or Hg
- Pro rated 5 year warranty
PPL 40AC 500W output; 40 LED 80-260VAC; $519.00 each. No transformer required.
PPL 2412 375W output; 24 LED; 12V; $449.00
TX.5A with plug for the PPL 2412; 12V 4 Amp $32.90
The 12 and 24 V LED Project lights require the use of a transformer if you wish to run the project lights from line voltage. We carry a number of different 12 and 24 VDC transformers. You'll find those here. The LED Project lights are also suitable for use with solar systems, wind generation systems and other battery systems within the input voltage tolerances stated.
Transformer help is here.
