10 Degree Angle UV LED SPECIFICATIONS
Please print this page to avoid ordering errors. LEDs and reflectors are not returnable.
|
UV LED radiates intense UV light during operation. DO NOT look directly into the UV light during operation of device. This can be harmful to the eyes even for a brief period due to the intense UV light. If viewing the UV light is necessary, use UV filtered glasses to avoid damage by the UV light. If the UV LED in your product might be viewed directly, affix a CAUTION LABEL to your product to that effect. Avoid direct eye exposure to UV light. KEEP OUT OF REACH OF CHILDREN. Download
and print the disclaimer - click here |
|
Characteristics: |
Applications:
|
Narrow Directivity
1/2)
: 10°
Maximum Ratings (Ta = 25° C)
|
Item
|
Symbol
|
Absolute
Maximum Rating
|
Unit
|
||
|
DC
Forward Current
|
 |
15
|
mA
|
||
|
Pulse
Forward Current*
|
 |
30
|
mA
|
||
|
Allowable
Reverse Current
|
 |
85
|
mA
|
||
|
Power
Dissipation
|
 |
60
|
mW
|
||
|
Operating
Temperature
|
 |
-30
~ +85
|
°
C
|
||
|
Storage
Temperature
|
 |
-40
~ +100
|
°
C
|
||
* Pulse width max 10ms Duty Ratio Max 1/10
Opto-Electrical Characteristics (Ta = 25° C)
|
Item
|
Symbol
|
Condition
|
Min
|
Typ
|
Max
|
Unit
|
|
DC
Forward Voltage
|
 |
IF=10mA
|
--
|
3.5
|
4.0
|
V
|
|
Optical
Power Output
|
PO
|
IF=10mA
|
--
|
750
|
--
|
mW
|
|
Peak
Wave Length
|
 |
IF=10mA
|
--
|
375
|
--
|
nm
|
|
Spectrum
Half Width
|
 |
IF=10mA
|
--
|
12
|
--
|
nm
|
