High Power Full Color RGB LED SPECIFICATIONS
Please print this page to avoid ordering errors. LEDs and reflectors are not returnable.
Characteristics:
High Power Full Color LEDs
Lens Color: Milky Diffusion
Superior Weather Resistance
UV Resistant EpoxyApplications:
Full Color Displays and IlluminationsLuminous Material
Blue: InGaN
Green InGaN
Red: AlInGaP
Maximum Ratings (Ta = 25° C)
| Characteristic |
Symbol
|
Rating
|
Unit
|
||
|
Blue
|
Green
|
Red
|
|||
| DC Forward Current |
 |
30
|
30
|
50
|
mA
|
| Pulse Forward Current* |
 |
100
|
100
|
200
|
mA
|
| Reverse Voltage |  |
5
|
V
|
||
| Power Dissipation** |
 |
120
|
mW
|
||
| Operating Temperature |
 |
-30
~ +85
|
°
C
|
||
| Storage Temperature |
 |
-40
~ +100
|
°
C
|
||
* Pulse width max 10ms Duty Ratio Max 1/10
**Value for one LED device (single color). Total value should be within the absolute maximum rating when illuminating more than two devices (full colors).
Opto-Electrical Characteristics (Ta = 25° C)
|
Characteristic
|
Symbol
|
Test
Condition
|
Blue
|
Green
|
Red
|
Unit
|
||||||
| Min | Typ | Max | Min | Typ | Max | Min | Typ | Max | ||||
|
DC
Forward Voltage
|
 |
IF
= 20mA
|
-- | 3.6 | -- |
--
|
3.5 | -- |
--
|
1.9 | -- |
V
|
|
DC
Reverse Current
|
 |
VR
= 5V
|
--
|
-- | 50 |
--
|
-- | 50 |
--
|
-- | 50 |
mA
|
|
Luminous
Intensity
|
 |
IF
= 20 mA
|
--
|
0.11 | -- |
--
|
0.52 | -- |
--
|
0.15 | -- |
cd
|
|
Chromacity
Coordinates*
|
x
|
IF
= 20 mA
|
--
|
0.13 | -- |
--
|
0.21 | -- |
--
|
0.70 | -- |
--
|
|
Chromacity
Coordinates*
|
y
|
IF
= 20 mA
|
--
|
0.07 | -- |
--
|
0.69 | -- |
--
|
0.30 | -- |
--
|
* Please refer to CIE 1931 chromacity diagram
