110-240 VAC LED Downlights - LED Ceiling Lights

3x3W LED Downlights

7X1W LED Downlights

LED Downlight Fixtures are equipped with a compact driver, which connects to your 110-240 VAC power. LED downlights can not be used in a 12vdc system.

3x3W LED downlights - Equivalent to the light output achieved from a 40W Halogen lamp with only 9.0-11.0W consumed.

7x1W LED downlights - Equivalent to the light output achieved from a 50W Halogen lamp with only 7W consumed.

All of our downlights are adjustable, which means that the interior circle where you see the LED's, is able to be pointed in the direction you would like the light to shine upon. Angle of adjustment is approximately 30 degrees. The view angle or light spread is 45 degrees for maximum light output and satisfactory light coverage from 8 to 20 feet away. Both LED downlights include the driver. Leads are 1 meter long. We have dimmable LED downlights in stock. Dimensional Drawing and Important Installation Notes

Specifications 3 x 3 W LED Downlights

• Input voltage: 85-260VAC; 50-60Hz
• Constant Current: 450mA +- 5%
• Diameter: 90mm W x 107.5mm D (3.5" x 4.2")
• Installation Hole: 71mm (2.76")
• Operating Temperature: -20° C to +50° C ( -4° F to 122° F)
• Power consumption: 9.0 +- 5%
• Color Temperature: 6000-6500K Cool White; 2800-3300K Warm White
• CRI: 75 DL; 80 WW
• Luminous Flux: 450 lumens CW; 400 lumens WW
• View Angle: 45 degrees
• Halogen comparison: Equivalent to a 40W Halogen Lamp
• IP Rating : IP40. Not for outdoor or damp location use.
• Certifications: CE; RoHS Compliant



Specifications 7 x 1 W LED Downlights

• Input voltage: 85-260VAC; 50-60Hz
• Constant Current: 330mA +- 5%
• Diameter: 105mm W x 71mm D (4.13" x 2.80")
• Installation Hole: 88mm (3.47")
• Operating Temperature: -20° C to +50° C ( -4° F to 122° F)
• Power consumption: 7.0W +- 5%
• Color Temperature: 6000-6500K Cool White; 2800-3300K Warm White
• CRI:75 DL; 80 WW
• Luminous Flux: 500 lumens DL; 450 lumens WW
• View Angle: 45 degrees
• Halogen comparison: Equivalent to a 50W Halogen Lamp
• IP Rating: IP40; Not for outdoor or damp location use.
• Certifications: CE; RoHS Compliant
